Recessed LED Downlight INDAT-RSF-A15 with fixed beam angle 60°
INDAT-RSF-A15
Мodels Recessed LED Downlight INDAT-RSF-A15 with Fixed Beam Angle 60°
Recessed LED Downlight INDAT-RSF-A15 | SKU: INDAT-RSF-A15-⌀88
$
$
Specifications
Dimensions ......... Ø 88 mm H 47 mm
Weight ................. 110
Power .................. 5W / 7 W
Lumen .................. 400-560 LM
Input Voltage ...... 110 - 240 V
CCT ...................... 2700K, 3000K, 3500K, 4000K, 5700K
CRI ....................... Ra≥90, Ra≥95, Ra≥97
Beam angle ........ 60º
Dimmable ........... No
Lightsource ........ LED
Color .................... White
Material ............... Aluminum
IP rating ............... IP 20
Dimming Type .... TRIAC, 1-10V, DALI, Bluetooth mesh, Zigbee
Dimensions ......... Ø 88 mm H 47 mm
Weight ................. 110
Power .................. 5W / 7 W
Lumen .................. 400-560 LM
Input Voltage ...... 110 - 240 V
CCT ...................... 2700K, 3000K, 3500K, 4000K, 5700K
CRI ....................... Ra≥90, Ra≥95, Ra≥97
Beam angle ........ 60º
Dimmable ........... No
Lightsource ........ LED
Color .................... White
Material ............... Aluminum
IP rating ............... IP 20
Dimming Type .... TRIAC, 1-10V, DALI, Bluetooth mesh, Zigbee
Recessed LED Downlight INDAT-RSF-A15 | SKU: INDAT-RSF-A15-⌀105
$
$
Specifications
Dimensions ......... Ø 88 mm H 47 mm
Weight ................. 110
Power .................. 5W / 7 W
Lumen .................. 400-560 LM
Input Voltage ...... 110 - 240 V
CCT ...................... 2700K, 3000K, 3500K, 4000K, 5700K
CRI ....................... Ra≥90, Ra≥95, Ra≥97
Beam angle ........ 60º
Dimmable ........... No
Lightsource ........ LED
Color .................... White
Material ............... Aluminum
IP rating ............... IP 20
Dimming Type .... TRIAC, 1-10V, DALI, Bluetooth mesh, Zigbee
Dimensions ......... Ø 88 mm H 47 mm
Weight ................. 110
Power .................. 5W / 7 W
Lumen .................. 400-560 LM
Input Voltage ...... 110 - 240 V
CCT ...................... 2700K, 3000K, 3500K, 4000K, 5700K
CRI ....................... Ra≥90, Ra≥95, Ra≥97
Beam angle ........ 60º
Dimmable ........... No
Lightsource ........ LED
Color .................... White
Material ............... Aluminum
IP rating ............... IP 20
Dimming Type .... TRIAC, 1-10V, DALI, Bluetooth mesh, Zigbee
Recessed LED Downlight INDAT-RSF-A15 | SKU: INDAT-RSF-A15-⌀130
$
$
Specifications
Dimensions ......... Ø 130 mm H 71 mm
Weight ................. 260
Power .................. 13W / 15 W / 18W
Lumen .................. 1040-1440 LM
Input Voltage ...... 110 - 240 V
CCT ...................... 2700K, 3000K, 3500K, 4000K, 5700K
CRI ....................... Ra≥90, Ra≥95, Ra≥97
Beam angle ........ 60º
Dimmable ........... No
Lightsource ........ LED
Color .................... White
Material ............... Aluminum
IP rating ............... IP 20
Dimming Type .... TRIAC, 1-10V, DALI, Bluetooth mesh, Zigbee
Dimensions ......... Ø 130 mm H 71 mm
Weight ................. 260
Power .................. 13W / 15 W / 18W
Lumen .................. 1040-1440 LM
Input Voltage ...... 110 - 240 V
CCT ...................... 2700K, 3000K, 3500K, 4000K, 5700K
CRI ....................... Ra≥90, Ra≥95, Ra≥97
Beam angle ........ 60º
Dimmable ........... No
Lightsource ........ LED
Color .................... White
Material ............... Aluminum
IP rating ............... IP 20
Dimming Type .... TRIAC, 1-10V, DALI, Bluetooth mesh, Zigbee
Recessed LED Downlight INDAT-RSF-A15 | SKU: INDAT-RSF-A15-⌀185
$
$
Specifications
Dimensions ......... Ø 185 mm H 93 mm
Weight ................. 590
Power .................. 20W / 24W / 27W
Lumen .................. 1600-2160 LM
Input Voltage ...... 110 - 240 V
CCT ...................... 2700K, 3000K, 3500K, 4000K, 5700K
CRI ....................... Ra≥90, Ra≥95, Ra≥97
Beam angle ........ 60º
Dimmable ........... No
Lightsource ........ LED
Color .................... White
Material ............... Aluminum
IP rating ............... IP 20
Dimming Type .... TRIAC, 1-10V, DALI, Bluetooth mesh, Zigbee
Dimensions ......... Ø 185 mm H 93 mm
Weight ................. 590
Power .................. 20W / 24W / 27W
Lumen .................. 1600-2160 LM
Input Voltage ...... 110 - 240 V
CCT ...................... 2700K, 3000K, 3500K, 4000K, 5700K
CRI ....................... Ra≥90, Ra≥95, Ra≥97
Beam angle ........ 60º
Dimmable ........... No
Lightsource ........ LED
Color .................... White
Material ............... Aluminum
IP rating ............... IP 20
Dimming Type .... TRIAC, 1-10V, DALI, Bluetooth mesh, Zigbee
Recessed LED Downlight INDAT-RSF-A15 | SKU: INDAT-RSF-A15-⌀220
$
$
Specifications
Dimensions ......... Ø 220 mm H 98 mm
Weight ................. 740
Power .................. 30W / 36W / 40W
Lumen .................. 2400-320 LM
Input Voltage ...... 110 - 240 V
CCT ...................... 2700K, 3000K, 3500K, 4000K, 5700K
CRI ....................... Ra≥90, Ra≥95, Ra≥97
Beam angle ........ 60º
Dimmable ........... No
Lightsource ........ LED
Color .................... White
Material ............... Aluminum
IP rating ............... IP 20
Dimming Type .... TRIAC, 1-10V, DALI, Bluetooth mesh, Zigbee
Dimensions ......... Ø 220 mm H 98 mm
Weight ................. 740
Power .................. 30W / 36W / 40W
Lumen .................. 2400-320 LM
Input Voltage ...... 110 - 240 V
CCT ...................... 2700K, 3000K, 3500K, 4000K, 5700K
CRI ....................... Ra≥90, Ra≥95, Ra≥97
Beam angle ........ 60º
Dimmable ........... No
Lightsource ........ LED
Color .................... White
Material ............... Aluminum
IP rating ............... IP 20
Dimming Type .... TRIAC, 1-10V, DALI, Bluetooth mesh, Zigbee
Luminaire for lamps with INDAT-RSF-A15 base. Body supplied without lamp. Built-in luminaire with a thin decorative frame. Distinguished by a simple mounting method. Minimalistic and modern design. Clean basic shapes. Thin decorative frame allows to hide mounting irregularities if necessary.
INDAT-RSF-A15 luminaires have a small size and laconic design, so they fit well into the interior. For general lighting, directional light sources are evenly distributed on the ceiling or walls of the room.
Ceramic base with spring clip. Bulbs included.
INDAT-RSF-A15 luminaires have a small size and laconic design, so they fit well into the interior. For general lighting, directional light sources are evenly distributed on the ceiling or walls of the room.
Ceramic base with spring clip. Bulbs included.
A ceramic base with spring clip bulb is also included. The light source in the INDAT-RSF-A15 luminaires for ceiling and wall mounting are miniature LED lamps with a bayonet base.
- It saves energy — the required illumination is provided with less power of the lamps, because all the rays are spread only in the right direction, and not scattered to the sides;
- Heating of the luminaire is reduced — the thermal energy released during operation is mainly reflected forward in the form of infrared radiation;
- Heating of the luminaire is reduced — the thermal energy released during operation is mainly reflected forward in the form of infrared radiation;
Fixed Beam Angle
Wide beam light distribution for general lighting
Wide beam light distribution for general lighting
OptionS Recessed LED Downlight INDAT-RSF-A15
High-power LED
SDCM<3-Step
SDCM<3-Step
High-power LED
SDCM<5-Step
SDCM<5-Step
High-power LED
SDCM<5-Step
SDCM<5-Step
Different
sizes
sizes
Different color
temperatures
temperatures
Different light
distributions
distributions
Different housing
colors
colors
EMC-optimised
Long life
span
span
Reliable connector
TRIAC
Dimming
Dimming
1-10V
Dimming
Dimming
DALI
Dimming
Dimming
Bluetooth
mesh
mesh
Zigbee
Dimming
Dimming
Fixed Beam
Angle
Angle
Fixed Multiple
Angles (Narrov to wide)
Angles (Narrov to wide)
Fixed fastigiate
Angle
Angle
Fixed fastigiate
Angles (Narrov to wide)
Angles (Narrov to wide)
Giare index
Adjustable Beam
Angle
Angle
Adjustable Multiple
Angles (Narrov to wide)
Angles (Narrov to wide)
Adjustable fastigiate
Angle
Angle
Adjustable fastigiate
Angles (Narrov to wide)
Angles (Narrov to wide)
Deep
Anti-Dazzel
Anti-Dazzel
Horizontally
rotatable 350º
rotatable 350º
Vertically
adjustable 90º
adjustable 90º
Only-side
adjustable 30º
adjustable 30º
Rimless
Rimless
Two-side
adjustable 40º
adjustable 40º
Two-side
adjustable 40º (East-West)
adjustable 40º (East-West)
Two-side
adjustable 90º (North-South)
adjustable 90º (North-South)
IP level
Fog-proof
Indoor
used only
used only
Excellent heat
dissipation management
dissipation management
No harmful
UV/IR irradiation
UV/IR irradiation
Allowed to install on ordinary combustible material
