LED Tracklight INDAT-2CG/3CG/4CG-C03 with Adjustable Fastigiate Angle (Narrow to wide - 15º, 24º, 36º ⃝350º)
INDAT-2/3/4CG-C03
Мodels LED Tracklight INDAT-2CG/3CG/4CG-C03 with Adjustable Fastigiate Angle (Narrow to wide - 15º, 24º, 36º ⃝350º), 2/3/4-wires track
LED Tracklight INDAT-2CG/3CG/4CG-C03 | SKU: INDAT-2CG/3CG/4CG-C03-⌀70
$
$
Specifications
Dimensions ......... ⌀70mm L 85mm H 175mm
Weight ................. 280
Power .................. 6W/8W/10W
Lumen .................. 480-800 LM
Input Voltage ...... 110 - 240 V
CCT ...................... 2700K, 3000K, 3500K, 4000K, 5700K
CRI ....................... Ra≥90, Ra≥95, Ra≥97
Beam angle ........ 15º 24º 36º
Dimmable ........... No
Lightsource ........ LED
Color .................... Wihgt, Black
Material ............... Aluminum alloy
IP rating ............... IP 22
Dimming Type .... TRIAC, 1-10V, DALI, Bluetooth mesh, Zigbee
Installation .......... 2/3/4-wires track
Dimensions ......... ⌀70mm L 85mm H 175mm
Weight ................. 280
Power .................. 6W/8W/10W
Lumen .................. 480-800 LM
Input Voltage ...... 110 - 240 V
CCT ...................... 2700K, 3000K, 3500K, 4000K, 5700K
CRI ....................... Ra≥90, Ra≥95, Ra≥97
Beam angle ........ 15º 24º 36º
Dimmable ........... No
Lightsource ........ LED
Color .................... Wihgt, Black
Material ............... Aluminum alloy
IP rating ............... IP 22
Dimming Type .... TRIAC, 1-10V, DALI, Bluetooth mesh, Zigbee
Installation .......... 2/3/4-wires track
LED Tracklight INDAT-2CG/3CG/4CG-C03 | SKU: INDAT-2CG/3CG/4CG-C03-⌀90
$
$
Specifications
Dimensions ......... ⌀90mm L 130mm H 215mm
Weight ................. 2460
Power .................. 15W/18W/20W
Lumen .................. 1200-1600 LM
Input Voltage ...... 110 - 240 V
CCT ...................... 2700K, 3000K, 3500K, 4000K, 5700K
CRI ....................... Ra≥90, Ra≥95, Ra≥97
Beam angle ........ 15º 24º 36º
Dimmable ........... No
Lightsource ........ LED
Color .................... Wihgt, Black
Material ............... Aluminum alloy
IP rating ............... IP 22
Dimming Type .... TRIAC, 1-10V, DALI, Bluetooth mesh, Zigbee
Installation .......... 2/3/4-wires track
Dimensions ......... ⌀90mm L 130mm H 215mm
Weight ................. 2460
Power .................. 15W/18W/20W
Lumen .................. 1200-1600 LM
Input Voltage ...... 110 - 240 V
CCT ...................... 2700K, 3000K, 3500K, 4000K, 5700K
CRI ....................... Ra≥90, Ra≥95, Ra≥97
Beam angle ........ 15º 24º 36º
Dimmable ........... No
Lightsource ........ LED
Color .................... Wihgt, Black
Material ............... Aluminum alloy
IP rating ............... IP 22
Dimming Type .... TRIAC, 1-10V, DALI, Bluetooth mesh, Zigbee
Installation .......... 2/3/4-wires track
LED Tracklight INDAT-2CG/3CG/4CG-C03 | SKU: INDAT-2CG/3CG/4CG-C03-⌀100
$
$
Specifications
Dimensions ......... ⌀100mm L 145mm H 230mm
Weight ................. 640
Power .................. 25W/28W/30W
Lumen .................. 2000-2400 LM
Input Voltage ...... 110 - 240 V
CCT ...................... 2700K, 3000K, 3500K, 4000K, 5700K
CRI ....................... Ra≥90, Ra≥95, Ra≥97
Beam angle ........ 15º 24º 36º
Dimmable ........... No
Lightsource ........ LED
Color .................... Wihgt, Black
Material ............... Aluminum alloy
IP rating ............... IP 22
Dimming Type .... TRIAC, 1-10V, DALI, Bluetooth mesh, Zigbee
Installation .......... 2/3/4-wires track
Dimensions ......... ⌀100mm L 145mm H 230mm
Weight ................. 640
Power .................. 25W/28W/30W
Lumen .................. 2000-2400 LM
Input Voltage ...... 110 - 240 V
CCT ...................... 2700K, 3000K, 3500K, 4000K, 5700K
CRI ....................... Ra≥90, Ra≥95, Ra≥97
Beam angle ........ 15º 24º 36º
Dimmable ........... No
Lightsource ........ LED
Color .................... Wihgt, Black
Material ............... Aluminum alloy
IP rating ............... IP 22
Dimming Type .... TRIAC, 1-10V, DALI, Bluetooth mesh, Zigbee
Installation .......... 2/3/4-wires track
Luminaire for lamps with INDAT-RSF-A15 base. Body supplied without lamp. Built-in luminaire with a thin decorative frame. Distinguished by a simple mounting method. Minimalistic and modern design. Clean basic shapes. Thin decorative frame allows to hide mounting irregularities if necessary.
INDAT-RSF-A15 luminaires have a small size and laconic design, so they fit well into the interior. For general lighting, directional light sources are evenly distributed on the ceiling or walls of the room.
Ceramic base with spring clip. Bulbs included.
INDAT-RSF-A15 luminaires have a small size and laconic design, so they fit well into the interior. For general lighting, directional light sources are evenly distributed on the ceiling or walls of the room.
Ceramic base with spring clip. Bulbs included.
A ceramic base with spring clip bulb is also included. The light source in the INDAT-RSF-A15 luminaires for ceiling and wall mounting are miniature LED lamps with a bayonet base.
- It saves energy — the required illumination is provided with less power of the lamps, because all the rays are spread only in the right direction, and not scattered to the sides;
- Heating of the luminaire is reduced — the thermal energy released during operation is mainly reflected forward in the form of infrared radiation;
- Heating of the luminaire is reduced — the thermal energy released during operation is mainly reflected forward in the form of infrared radiation;
Adjustable Fastigiate Angle
Rotationally symmetrical light distribuyion for accent lighting. Meet the demand of accent lighting and spatial lighting for the bilding.
Rotationally symmetrical light distribuyion for accent lighting. Meet the demand of accent lighting and spatial lighting for the bilding.
Adjustable Fastigiate Angle
(Narrow to wide)
Rotationally symmetrical light distribuyion for accent lighting. Meet the demand of accent lighting and spatial lighting for the bilding.
(Narrow to wide)
Rotationally symmetrical light distribuyion for accent lighting. Meet the demand of accent lighting and spatial lighting for the bilding.
OptionS LED Tracklight INDAT-2CG/3CG/4CG-C003
High-power LED
SDCM<3-Step
SDCM<3-Step
Different
sizes
sizes
Different color
temperatures
temperatures
Different light
distributions
distributions
Different housing
colors
colors
EMC-optimised
Long life
span
span
Reliable connector
TRIAC
Dimming
Dimming
1-10V
Dimming
Dimming
DALI
Dimming
Dimming
Bluetooth
mesh
mesh
Zigbee
Dimming
Dimming
Horizontally
rotatable 350º
rotatable 350º
Vertically
adjustable 90º
adjustable 90º
IP level
Fog-proof
Indoor
used only
used only
Excellent heat
dissipation management
dissipation management
No harmful
UV/IR irradiation
UV/IR irradiation
Allowed to install on ordinary combustible material
